IRM-01-5S Switching power supply, module, 1W, 5V, 0.2A SMD, MEAN WELL
zoom_out_map
chevron_left chevron_right


Advertising [AfterProductThumbs]

IRM-01-5S Switching power supply, module, 1W, 5V, 0.2A SMD, MEAN WELL

IRM-01-5S Switching power supply, module, 1W, 5V, 0.2A SMD, MEAN WELL

€5.51

€5.51 Tax excluded


Advertising [ProductAdditionalInfo]

local_shipping FREE shipping on orders over $25.00 shipped by Amazon. Details


Advertising [Product3rdColumn]

Security policy
Site hosted and secured in Eu.
Delivery policy
Packages transported with the service of Bpost, DpD, PostNl or your own carrier.
Return policy
Defective devices (not electronic components) are (according to the manufacturer's warranty) exchanged or repaired.

Meanwell IRM-01 Miniature Power Supply Series Description:

IRM-01 is a 1W miniature (33.7*22.2*15mm) AC-DC module-type power supply, ready to be soldered onto the PCB boards of various kinds of electronic instruments or industrial automation equipment. The power supply allows a universal input voltage range of 85~305VAC. The phenolic case and the fully-potted silicone enhance the heat dissipation and fulfil anti-vibration requirements of up to 5G. In addition, the case provides resistance to dust and moisture. With a high efficiency of up to 77% and the extremely low no-load power consumption below 0.075W, the IRM-01 series corresponds to the worldwide regulation of low power consumption for electronics. The entire series fulfils the Class Il design (no FGpin) requirements, incorporating built-in EMI filtering components, which in turn enable the compliance with the EN55032 Class B standard. Due to the series' supreme EMC capabilities, the final electronic units/products will be kept from electromagnetic interference. In addition to the module-type model, the IRM-01 series is also available as a SMD model.

Meanwell IRM-01 Miniature Power Supply Series Features:

  • Closed design, PCB mounting
  • Universal input
  • Power consumption at no load<0.075W
  • Compact size
  • Protected against short circuit, overload and overvoltage
  • Cooling by free air convection
  • Low standby power consumption
  • Insulation class II
  • Safety standards: UL/EN62368-1
  • EMC Standard: EN55032 Class B
  • High reliability, low cost
  • 3 years manufacturer warranty
  • IRM-01: wired
  • IRM-01S: SMD
For detailed technical specifications, please check the data sheet in the "downloads" section.
