DDRH-60-48 DC/DC Converter 48V 1,25A 60W, MEAN WELL
zoom_out_map
chevron_left chevron_right

DDRH-60-48 DC/DC Converter 48V 1,25A 60W, MEAN WELL

DDRH-60-48 DC/DC Converter 48V 1,25A 60W, MEAN WELL

€64.30

€64.30 Tax excluded

check 21

local_shipping FREE SHIPPING  Belgium-France-Nederland-Germany on ALL PRODUCTS  for 125 € order

Security policy
Site hosted and secured in Eu.
Delivery policy
Packages transported with the service of Bpost, DpD, PostNl or your own carrier.
Return policy
Defective devices (not electronic components) are (according to the manufacturer's warranty) exchanged or repaired.

MEAN WELL DDRH-60 Series Description:

The DDRH-60 series are 150 ~ 1500Vdc ultra-high input DIN rail DC-DC converters which can supply stable working voltage for the load. They can be mounted on TS-35/7.5 or TS-35/15 rails. Main features are as follows: easy to install on DIN rail , slim design with narrow width (67mm), -30~+80°C wide operating temperature range, 4KVAC high isolation voltage, operation at 5000m altitude, high efficiency, low ripple & noise, etc.. The DDRH-60 series is compliant with the BS EN/EN61000-6-2 standard regarding immunity for industrial environments. It is suitable for industrial automation, surveillance, telecommunication and can be widely used in renewable energy applications such as solar or windmill power generation. Specific application examples are: photovoltaic power systems, high voltage inverting , DC bus centralized applications, etc.

MEAN WELL DDRH-60 Series Features:

  • For DIN rail mounting
  • Can be installed on TS-35/7.5 or 15 DIN rail
  • 150~ 1500Vdc 10:1 ultra wide input range
  • 57mm narrow width
  • 4KVac I/O high isolation (reinforced insulation).
  • Protection functions: Short circuit / overload / over voltage / over temperature / DC input undervoltage / reverse polarity.
  • Cooling by free air convection
  • Built-in DC-OK relay contact
  • No minimum load required
  • Output voltage adjustable (±20%)
  • Operating altitude up to 5000 m
  • Overvoltage category II
  • EMC standards: EN55032 Class A
MEAN WELL
DDRH-60-48
21 Items
DDRH-60-48
