LC-WM-Relay-5V
Bluetooth relay module mobile phone bluetooth remote control
Advertising [ProductAdditionalInfo]
local_shipping FREE shipping on orders over $25.00 shipped by Amazon. Details
Advertising [Product3rdColumn]
Site hosted and secured in Eu.
Packages transported with the service of Bpost, DpD, PostNl or your own carrier.
Defective devices (not electronic components) are (according to the manufacturer's warranty) exchanged or repaired.
1. Summarize
LC 5V bluetooth relay board include single channel 5V/10A relay module and SPP-C bluetooth serial port slave module, Can be sent via mobile phone APP commands to control the relay switch.
2. Functional features
(1) Onboard SPP - C bluetooth serial port slave module, with wireless control function.
(2) Onboard 5V,10 A / 250 V AC 10 A / 30 V DC relay, relay long life can absorb 100000 times in a row.
(3) Module with diode effusion protection, short response time.
(4) Onboard bluetooth status indicator light (when not connected flash, slow connection after long bright) and relay status indicator light .
(5) Control distance 10m (open environment)
Technical parameters:
Follow the bluetooth 2.1 + EDR specification
Module working voltage VCC: DC 5 v
DC control maximum voltage: DC 30 v
Exchange control maximum voltage: AC 250 v
3. Introduce of hardware
Size: 20mm*62mm
4. The basic function and instructions
IN + : DC 5V power supply to the anode
IN - : DC 5V power supply
COM: public side
NO: relay normally open interface, relay and impending, before and after absorption and COM sub.
NC: relay normally closed interface, relay and with COM nipple, before and after the impending.
Basic instructions:
After wiring correct, using cellphone to search Bluetooth devices and connect, Pairing password is 1234，Input order and send by hexadecimal (when the Input order is A00101A2 open the relay , when the Input order is A00100A1 close the relay)
Note:
When Wiring NO NC COM:
Cann’t access to any two port ,or will be short circuit.
After buying, you will receive step by step manual
Note: For this wifi relay module,because there some counterfeit on other sales platform. So if the on-board LED(D2) are blink constantly(I guess the reason is the STC15F104W haven't been programed), it means the module
